3DGuide MedSafe

3D Guidance medSAFE

Medically Compliant: Class 1, Type CF, Defib Proof

Electronics unit with multiple sensor and transmitter options

Guide Medical Instruments with Passive DC Magnetic Sensors

Track multiple miniaturized sensors simultaneously.

Localize in 3D without ionizing radiation.

Guide flexible tools without line-of-sight restrictions.

No "power-line" noise interference.

Navigate catheters, probes, and scopes with low

cost, disposable sensors.

Multiple transmitter options enable use in medical environments

once unsuitable for magnetic tracking.

medSAFE's miniaturized sensors are

routinely deployed in medical

instruments and catheters for

safer and less intrusive tracking

and localization. Here a 1.3 mm

sensor is seen protruding from the

working channel of a bronchoscope.

Sensors with sub-millimeter diameters are available to extend

the reach of catheters and scopes deep into the periphery of

organs and vessels.

PRECISE

UNOBTRUSIVE

AFFORDABLE

3D Guidance medSAFE

Technical

Interchangeable

sensor sizes for

Sensor Configurations

Model 800 (8.0 mm), Model 180 (2.0 mm)

full six degrees-

Model 130 (1.5 mm)

of-freedom

Degrees of Freedom

6 (Position and Orientation)

tracking

Update Rate

· Short & Mid-Range Transmitter

up to 375 updates/second for each sensor

· 6DOF Flat (Metal-Immune) Transmitter

up to 162 updates/second for each sensor

Translation Range

M O D E L 800 SENSOR

· Mid-Range Transmitter: 78 cm in any direction

· Short-Range Transmitter: 46 cm in any direction

· Flat Transmitter: 46 cm in Z direction

MODEL 180 SENSOR

· Mid-Range Transmitter: 58 cm in any direction

· Short-Range Transmitter: Contact Ascension

for latest test results.

F E AT U R E

BENEFITS

· Flat Transmitter: 46 cm in Z direction

MODEL 130 SENSOR

Metal tolerant

80% less distortion due to non-magnetic

· Mid-Range Transmitter: 46 cm in any direction

conductive metals compared to AC

· Short-Range Transmitter: Contact Ascension for latest

magnetic trackers. Outputs unaffected

test results.

by composite materials. Capable of

· Flat Transmitter: 46 cm in Z direction

driving errors induced by highly

Angular Range

All Attitude: ± 180° Azimuth & Roll; ± 90° Elevation

conductive metals (such as aluminum) to

Static Accuracy*

Position: 1.4 mm RMS

zero by adjusting measurement rate.

Orientation: 0.5° RMS

*Higher accuracies achievable in smaller tracking

Advanced new

Flat transmitter with ferrous metal shield

volumes.

magnetic technology

negates distortions produced by

*Accuracies vary depending on specific

and signal processing

procedural tables. Outputs immune

transmitter-sensor configurations.

to "power-line" noise sources.

Static Resolution

Position: 0.5 mm @ 30.5 cm

Orientation: 0.1° @ 30.5 cm

Occlusion and drift free

Accuracy of measurements unaffected

Outputs

X, Y, Z positional coordinates, orientation angles,

by insertion of sensors into human body.

orientation matrix, or quaternions

Low cost sensors

Designed for disposability in volume

Interface

RS-232, USB, Ethernet (factory option)

applications.

Data Format

Binary data records

Software support

XP/Pro and XP embedded compatible

Windows API and DriversPhysical

Communication

with SDK and sample programs. API with

expert support facilitates incorporation

Physical

into user applications. Fully integrated

with partners' medical imaging software

Electronics Unit

27.9 cm x 27.3 cm x 6.4 cm

for 3D rendering and visualization of

Transmitters

3 Options: Short-Range (6.27 cm x 4.6 cm x 5.2 cm with

anatomical structures.

3.3 m cable); Mid-Range (9.6 cm cube with 3.3 m cable);

Flat (Metal-Immune): Contact us.

Passive Sensors

M O D E L 800 : 8 mm OD; 20 mm length

Regulatory Certifications

with 3.8 mm OD cable, 3.3 m in length

Medically Compliant: Class 1 Medical Device, Type CF, Defib Proof

(Applied Parts)

M O D E L 180 : 2.0 mm OD;

9.7 mm length with 1.2 mm OD cable, 2 m in length

3D Guidance users must obtain and comply with all pertinent FDA/CE/IRB and international

M O D E L 130 : 1.5 mm OD;

medical certifications prior to using this device in humans. Biomedical references in this

7.7 mm length with 1.2 mm OD cable, 2 m in length

document are examples of what medical practitioners can do with 3D Guidance after

complying with all regulatory requirements. Users must comply with all pertinent electrical,

Model 180 & 130 only:

safety and medical regulations prior to inserting sensors and cables into patients.

· Ascension Medi-Mag Cable, USP class 6 jacket material.

· USP class 6 sensor housing.

Notes on Accuracy

· Sensor assembly and cable materials are EtO and cold

sterilant tolerant. Warning: Semiconductor devices in

Accuracy is defined as the root mean square (RMS) deviation of a true-measurement

sensor connector are not gamma shielded and may

of the magnetic center of a single sensor with respect to the magnetic center of a single

be damaged or erased if exposed to gamma radiation

transmitter measured over the specified translation range. Accuracy varies from one

and/or autoclaving.

location to another over this range and will be degraded if there are interfering electro-

· Sensors and cable assemblies are fragile components

magnetic noise sources or metal in the operating environment, which have not been

and must be sheathed and safeguarded prior to use in

identified and minimized.

patients.

Power

100-240V ~ 50/60Hz

Operating Temperature

15°C to 35°C; 95% non-condensing humidity

Environment

Ferromagnetic objects and stray magnetic fields in the

operation volume may degrade performance. Contact us

for assistance in using our Optimization Tools to

minimize metallic distortion and noise interference.

www.ascension-tech.com | P.O. Box 527 | Burlington, VT 05402 USA | (802) 893-6657 | USA: (800) 321-6596
